Описание
CPU |
Quad-core 1.8 GHz |
Hardware L7 engine |
Yes |
Memory |
DDR3 1 GB |
Antenna type |
2T2R + 4T4R omnidirectional high-gain dipole (2.4 GHz/5 GHz) |
RJ-45 ports |
• 1 x Gigabit WAN • 1 x 2.5GbE configurable WAN/LAN • 3 x Gigabit LAN |
External ports |
1 x USB 3.2 Gen 1 (Type-A) |
Size (HxWxD) |
175 mm x 320 mm x 200 mm (antennas in upright position) |
AC adapter input voltage |
100 V to 240 V AC |
Power frequency |
50 to 60 Hz, single phase |
Operating environment |
• 5°C to 40°C (40°F to 104°F) • 8% to 80% RH |
Storage environment |
• -20°C to 60°C (-5°F to 140°F) • 5% to 95% RH |
Maximum operating altitude |
5,000 m (16,400 ft) |
Wireless
Wireless standards |
• IEEE 802.11 a/n/ac/ax simultaneous tri-band • 802.11k/v/r roaming support |
Max. data rate |
• 2.4 GHz: Up to 600 Mbps • 5 GHz-1: Up to 4800 Mbps • 5 GHz-2: Up to 1200 Mbps |
Wireless security |
WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, Wi-Fi Enhanced Open (OWE), Wi-Fi Protected Setup (WPS) 2.0 |
Other wireless functions |
Smart Connect for automatic band steering, independent Wi-Fi schedule ON/OFF, guest network |
Features
Operation modes |
|
DHCP |
Server/client mode, client list, MAC address reservation |
Port forwarding |
DMZ, UPnP, VPN pass-through (PPTP, IPSec, L2TP, SIP) |
Parental control |
Per-device configurable internet schedule, allow/block list, DNS-based web filter with built-in database, YouTube, Google, and Bing search integration, supports Google Safe Browsing |
Traffic control |
• Per-device custom speed, traffic monitoring, per-application limits, and advanced usage reporting • Application Layer (Layer 7) monitoring and management |
Network tools |
Ping, Traceroute, WoL over Synology QuickConnect integration |
Security |
• Denial of service (DoS) protection and IP auto block mechanism • SSL certificates with Let's Encrypt integration • Synology Security Advisor • Two-factor authentication |
Network separation |
Max. number of VLANs: 5 |
VPN clients |
PPTP, OpenVPN™, L2TP over IPSec |
IPv6 support |
IPv6 DHCP server / client, DS-Lite, 6in4, 6to4, 6rd, Dual-Stack, DHCPv6-PD, IPv6 Relay, FLET's IPv6 |
Backup solutions |
Back up & restore SRM configuration, Time Machine support (with attached USB storage device) |
Notifications |
Email, SMS, push service (via DS router) |
File service |
SMB, AFP, FTP/FTPS, WebDAV |
FTP server |
Bandwidth control for TCP connections, custom FTP passive port range, anonymous FTP, FTP SSL/TLS and SFTP protocols, transfer logs |
iOS/Android™ applications |
DS router, VPN Plus, DS cloud, DS file, DS get (Android™) |
Anywhere access |
Synology QuickConnect, Dynamic DNS (DDNS) |
Printer support |
• Max. number of printers: 1 • Printing protocols: LPR, CIFS, IPP |
Advanced functions |
Smart WAN - Dual WAN load balancing and failover, policy route, static route, network address translation (NAT), SNMP, SSH, LAN/WLAN IGMP snooping, PPPoE relay |
Supported browsers |
Google Chrome®, Firefox®, Microsoft Edge®, Safari® 13 and later, and Safari (iOS 13.0 and later) on iPad, Chrome (Android™ 11.0 and later) on tablets |
Interface languages |
English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svensk, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, |
Характеристики
| Производител | Synology |
| Тип мрежово устройство | Router - маршрутизатор |
| WiFi стандарт | WiFi 6 |
| WLAN скорост | до 6000 Mbps |
| Рутер брой антени | 6 |
| Рутер/AP екстри | 1 x USB 3.0 порт |
| LAN скорост | 2.5 Gigabit |
| Цвят: | Черен |
| Гаранция | 2 години гаранция |
