Описание
- Процесор - Supports Intel® Core™ Ultra Processors (Series 2) (LGA1851)
- Supports Intel® Hybrid Technology
- Supports Intel® Turbo Boost Max 3.0 Technology
- Supports Intel® Термално усилване на скоростта (TVB)
- Supports Intel® Адаптивна усилваща технология (ABT)
- Интегриран NPU за специално AI ускорение - Чипсет - Intel® H810
- Памет - Dual Channel DDR5 Memory Technology
- 2 x DDR5 DIMM Slots
- Supports DDR5 non-ECC, un-buffered memory up to 6400
- Supports Clocked Unbuffered DIMM (CUDIMM)
- Max. capacity of system memory: 128GB*
- Supports Intel® Изключителен профил на паметта (XMP) 3.0x - BIOS - 256Mb AMI UEFI Legal BIOS with GUI support
- Графика - Intel® Xe LPG Графична архитектура
- 1 x HDMI 2.1 TMDS/FRL 8G съвместим, supports HDR, HDCP 2.3 and max. резолюция up to 4K 120Hz
- 1 x Порт за дисплей 1.4 с DSC (компресиран), поддържа HDCP 2.3 и макс. резолюция до 8K 60Hz / 5K 120Hz
- 1 x D-Sub, supports max. резолюция up to Full HD (1920x1080) 60Hz - Аудио - 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
- LAN - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
- Dragon RTL8125BG
- Supports Dragon 2.5G LAN Software
- Smart Auto Adjust Bandwidth Control
- Visual User Friendly UI
- Visual Network Usage Statistics
- Optimized Default Setting for Game, Browser, and Streaming Modes
- User Customized Priority Control - Слотове CPU:
- 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode
Chipset:
- 1 x PCIe 4.0 x1 Slot (PCIE2)*
- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module - Съхранение Chipset:
- 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode
- 4 x SATA3 6.0 Gb/s Connectors - USB Chipset:
- 1 x USB 3.2 Gen1 Type-C (Front)
- 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front)
- 6 x USB 2.0 (4 Rear, 2 Front) - Конектор - 1 x SPI TPM Header
- 1 x Power LED and Speaker Header
- 1 x RGB LED Header
- 2 x Addressable LED Headers
- 1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)
- 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control)
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
- 1 x Front Panel Type C USB 3.2 Gen1 Header - Заден панел с входове и изходи - 2 x Точки за закрепване на антената
- 1 x PS/2 Mouse/Keyboard Port
- 1 x D-Sub Port
- 1 x HDMI Port
- 1 x Порт за дисплей 1.4
- 2 x USB 3.2 Gen1 Ports
- 4 x USB 2.0 Ports
- 1 x RJ-45 LAN Port
- HD Audio Jacks: Line in / Front Speaker / Microphone - Софтуер и UEFI Software
- ASRock Motherboard Utility (A-Tuning)
- ASRock Dragon 2.5G LAN Software
- ASRock Polychrome SYNC
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- Програма за инсталиране на автоматични драйвери на ASRock
- ASRock Мигновен Flash - Аксесоари - 1 x I/O Shield
- 2 x SATA Data Cables
- 1 x Screw for M.2 Socket - Форм фактор - Micro ATX Form Factor: 8.66-in x 7.6-in, 22.0 cm x 19.3 cm
- OC - Microsoft® Windows® 11 64-bit
- Сертификати - FCC, CE
- ErP/EuP ready (ErP/EuP ready power supply is required)
Характеристики
| Производител | AsRock |
| Процесор - сокет | Intel 1851 |
| Дънна платка- чипсет | Intel H810 |
| Дънна платка- брой RAM слота | 2 |
| RAM поддръжка | DDR5 |
| Размери Форм фактор | Micro-ATX |
| Гаранция | 3 години гаранция |
| Ръководство за употреба | Ръководство на потребителя за дънни платки |
